Will this pickup only work with Pico's Auto scopes or can it be used with lower voltage range scopes, ie Pico 2206B

I have a Pico 2206B, +/-20V pk max, that I use with a 20:1 attenuator. I am wondering if this pickup will work with my Pico scope.

Status: Open Mar 11, 2021 - 12:23 PM

Comments (0) | New Comment

Add New Comment

Do you have the same question? Follow this Question

Answer this question Report it

1answer

Answer

Scott

Mar 11, 2021 - 01:17 PM

BNC+ is not designed to work on a standard twist-to-lock BNC connector. It will not lock on to the scope and would lose connection easily.

This is the appropriate secondary probe for a 2206B or other scopes.
https://www.aeswave.com/Secondary-Ign...

Source: SA

Report it

Comments (0) | New Comment

Add New Comment

Answer this question

View More Product Details

Will this pickup only work with Pico's Auto scopes or can it be used with lower voltage range scopes, ie Pico 2206B

Secondary Ignition Pickup with PicoBNC (TA397)
