Answer
May 11, 2016 - 01:31 PM
You can find the probe calibration on your uScope by following these instructions:
Probe Cal (Probe Calibration)
· Use the LEFT/RIGHT arrow keys to navigate to the “Menu” icon
· Open your “Menu” icon by highlighting and pressing the “OK” button
· Open the “Vertical” Menu item in the pop-up window by highlighting and pressing “OK” button
· Use the UP/DOWN arrow keys to navigate to “Probe Cal”
· At the top left of the screen, while “Probe Cal” is highlighted, the uScope will specify what attenuation setting you are currently on (Note: 10x does not change anything within the scope other than the voltage settings will be 10x larger – 1volt per division will read 10 volt per division
· Use the LEFT/RIGHT to pick the desired attenuation/calibration
· Press “OK” to exit the menu
